Stainless steel semi-jet centrifugal pump

Specification of Stainless steel semi-jet centrifugal pump

Leo stainless steel semi-jet centrifugal pump

• Leo Jet pumps can be used to drain liquids with physical and chemical properties such as water.

• This pump is suitable for lifting water from wells, garden irrigation, increasing the pressure of running water, and supporting equipment, etc.

Features of Leo stainless steel semi-jet centrifugal pump

• Pump body made of cast iron and supported by special anti-rust treatment

• The impeller is made of stainless steel

• AISI 304 shaft

• Maximum liquid temperature is + 40 ° C

• Max. Suction + 9m

Motor Features of Leo stainless steel semi-jet centrifugal pumps

• C&U bearings

• Motor with copper windings

• Embedded heat protection for single phase motors (220V)

• Insulation Class F

• IPX4 Protection Class

• Max indoor temperature + 40 ° C

Specifications of Leo stainless steel semi-jet centrifugal pumps

• Power: 300 watts

• Power: 0.4 HP

• Voltage: 220 Volts

• Max capacity : 40 lpm

• Maximum total head: 25 mtr

• Impeller material: stainless steel

• Body: cast iron

• Max working & room temperature: + 40 ° C
