Specification of Stainless steel semi-jet centrifugal pump
Leo stainless steel semi-jet centrifugal pump
• Leo Jet pumps can be used to drain liquids with physical and chemical properties such as water.
• This pump is suitable for lifting water from wells, garden irrigation, increasing the pressure of running water, and supporting equipment, etc.
Features of Leo stainless steel semi-jet centrifugal pump
• Pump body made of cast iron and supported by special anti-rust treatment
• The impeller is made of stainless steel
• AISI 304 shaft
• Maximum liquid temperature is + 40 ° C
• Max. Suction + 9m
Motor Features of Leo stainless steel semi-jet centrifugal pumps
• C&U bearings
• Motor with copper windings
• Embedded heat protection for single phase motors (220V)
• Insulation Class F
• IPX4 Protection Class
• Max indoor temperature + 40 ° C
Specifications of Leo stainless steel semi-jet centrifugal pumps
• Power: 300 watts
• Power: 0.4 HP
• Voltage: 220 Volts
• Max capacity : 40 lpm
• Maximum total head: 25 mtr
• Impeller material: stainless steel
• Body: cast iron
• Max working & room temperature: + 40 ° C
Untuk keterangan lebih lanjut, silahkan download PDF ini :
