Handal Red and Green are a series of solar water heaters with capacities of 300, 180 and 150 liters for Handal Red and 150 liters for Handal Green. Handal Red and Green are an economical solution to hot water baths for small modern families (Smart Living). Handal is made tough and is an environmentally friendly product, saves energy and supports the blue sky program/reducing the effects of global warming.
This reliable water heater has 7 advantages, namely
1. Reliable product quality and guarantee supported by the Solehart factory which has a quality guarantee and has been tested by ISO 9001 - 2015
2. Reliable products have been produced and marketed since 1991 throughout Indonesia.
3. sales and service network of more than 40 dealers in 33 provincial capitals
4. Guaranteed spare parts are always available
5. Reliable product manufacturing is carried out in the Jabebeka - Cikarang industrial area, not home industry.
6. Technical personnel whose quality is always maintained with regular training from PT Bernadi Utama as Producer to guarantee the quality of installation and maintenance services
7. Reliable Population as the market leader for solar water heaters is currently spread throughout Indonesia from Sabang to Merauke
wind: pressurized tank
tank material = 2.5 low carbon steel with 2 coats prime glaze vitreous enamel lining
tank pressure test = 21 kg cm^2/2100 kpa (300psi)
tank insulation = polyurethane foam
tank skin = 0.31 Zincalume Coated
Tank side cover = polypropylene with UV stabilizer
Tank capacity 150 liters
empty weight = 82kg
overall weight = 233.5kg
tank dimensions (1270mm x 510 mm x 510 mm)
Overall installed dimensions = 2452 mm x 1270 mm x 510mm
bakcup element heater = 1.0 kw (4.5 A)
Optional Element Heater = 1.8 kw (8.2 A)
Number of collectors = 1
Optional Number of Collectors =
Collector dimensions = (1937mm x 1025mm x 80mm)
Collector Box = 0.65mm aluminum
Collector cover glass = Low Iron Tempered Frosted Glass 3.2 mm
Heat Collector Cross-section = Copper pipe and 0.31 mm aluminum plate
Absorber Coating = Black Matte Paint
Absorber Bonding = Laser Welded
Collector Heat Insulation = Glass wool 50 mm (bottom), Polystyrene (sides)
Collector Pressure Test = 7 kg/ cm^2 (700 kpa)
Operational Cold Water Pressure = 6.5 kg / cm^2 (650 kpa)
Maximum Hot Water Pressure = 10 kg/cm^2 ( 1000kpa) at 99 C
